Illite Grinding Mill

Illite mill finished product fineness : 325 mesh ~ 3000mesh. The brief introduction about illite : Illite is a common kind of clay minerals, produced in pelite, usually weathering by white micaand potassium feldspar, or formed by the alte

Over View
Features
Applications
Technical Data

Illite mill finished product fineness: 325 mesh ~ 3000mesh.

The brief introduction about illite

Illite is a common kind of clay minerals, produced in pelite, usually weathering by white micaand potassium feldspar, or formed by the alteration of other minerals. It is also the middle transitional mineral to the formation of other clay minerals. Pure illite clay is white, butbecause it contains impurities,which was dyed yellow, green, brown and other colors.Underside cleaves completely. Mohs’s hardness is 1~2. Specific gravity is 2.6~2.9.

Illite has potassium-rich, high aluminum, low iron and smooth, bright, delicate, heat resistance etc. superior chemical and physical properties. Illite clays can serve as novel ceramic raw materials, fluxes of heat resistant cylinders and cosmetic or plastic packing. Besides, it can be adsorption of cesium in nuclear waste processing to exert radiation effects. Pure white illite can replace kaolin as paper coating, as well as for the production of car shell sprayed materials, welding electrodes, and so on.

Illite has wide industrial use, can be used to produce potash, advanced coatings, fillers, ceramic parts, advanced cosmetics, soil conditioning agent skeleton ingredients, high-rise building, poultry feed additive and cement batching, nuclear industrial purification of pollution and environmental protection. Trace element can be made of the outer coating of space shuttle.

Especially in three industries of paper making, cosmetics, ceramic, illite has a great value.

Scope of application of theIllite mill

Illite Grinding Mill is mainly applied to non-inflammable, non-explosive and brittle materials with Mohs hardness under seven, such as calcite, chalk, limestone, dolomite, carbon black, bentonite, kaolin, talc, mica, magnesite, illite,pyrophyllite , roseite, sea-foam, attapulgite , rectorite, diatomite, barite, gypsum, alunite, graphite, fluorite,  rock phosphate, kalium ore, pumice etc.  totally more than 100 kinds of materials.

Finished powder products are in the 325meshs -3000meshs, and yield can be up to 0.7-7.5 tons per hour. There are four types of Shanghai Clirik HGM series manufacture grinding mill, they are HGM8021, HGM9024, HGM10027, and HGM10036.

Illite mill grinder (industrial grinding machine) devices:

Illitemill grinder(industrial grinding machine) mainly consist of hammer crusher , micro powder main unit, Frequency conversion classifier, powder collector, pulse dust cleaner,high pressure positive blower, air compressor, muffler, electrical apparatus control system, sound-proof room, crusher, bucket elevator, storage hopper, and vibrating feeder.

  • High efficiency

Under the same finished final size and the same motor power, the capacity of micro powder grinding mill is twice as much as jet mill, mixing grinder and ball mill.

  • Long lifecycle of spare parts

The ring and roller are forged by special material with high utilization. Under the same grinding material and finish special size, the lifecycle of spare parts is about one year, which is 2-3times longer than impact mill or turbo mill. Furthermore, the lifetime can reach 2-5 years for grinding calcite carbonate.

  • High safety and reliability

As no rolling bearings or screws in grinding cavity, there are no problems caused by bolts shedding or rapid wear of bearings and seal components.

  • High fineness and flexible adjustment

The final fineness of the grinding materials can be adjusted between 325 meshes and 3000 meshes, and the product fineness can reach D97≦5um.

  • Environment-friendly

The application of pulse deduster and muffler greatly alleviates dust pollution and noise.

Illite Grinding Mill is mainly applied to non-inflammable, non-explosive and brittle materials with Mohs hardness under seven, such as calcite, chalk, limestone, dolomite, carbon black, bentonite, kaolin, talc, mica, magnesite, illite,pyrophyllite , roseite, sea-foam, attapulgite , rectorite, diatomite, barite, gypsum, alunite, graphite, fluorite,  rock phosphate, kalium ore, pumice etc.  totally more than 100 kinds of materials.

Parameters of HGM Series Ultrafine Grinding Mill
Model HGM80 HGM80A HGM90L HGM100L-Ⅱ HGM100P HGM125L HGM1680L
Ring Diameter(mm) 800 800 900 1000 1000 1250 1680
Ring Number (PCS) 3 3 4 4 4 4 4
Input Size (mm) ≤10 ≤10 ≤10 ≤15 ≤15 ≤20 ≤20
Output Size (mesh) 150-3000 150-3000 150-3000 150-3000 150-3000 150-3000 150-3000
Capacity (t/h) 0.5-5.5 0.5-5.5 0.8-6.5 1.2-10 1.2-11 2.5-20 5-45
Outlet Size L*W*H (mm) 8605*4139*6050 10454*3393*6626 11735*3952*7525 14507*3633*7562 14362*4200*7562 19261*4406*8591 25067*5414*9007
Main Motor Power (kw) 75 75 55*2 132/75*2 132/75*2 185 315
